凱頓Kaydon外齒內法蘭四點接觸球轉盤軸承RK6-**E1Z系列回轉支承型號：
| 型號 |
規格 |
重量 | |||||
| Do | di | H | Di | do | dr | kg | |
| RK6-16E1Z | 505.5 | 304 | 56 | 412 | 410 | 368 | 33 |
| RK6-22E1Z | 638.8 | 434 | 56 | 542 | 540 | 498 | 44 |
| RK6-25E1Z | 740.4 | 534 | 56 | 642 | 640 | 598 | 52 |
| RK6-29E1Z | 835.7 | 634 | 56 | 742 | 740 | 698 | 58 |
| RK6-33E1Z | 944.9 | 734 | 56 | 842 | 840 | 798 | 69 |
| RK6-37E1Z | 1046.5 | 834 | 56 | 942 | 940 | 898 | 78 |
| RK6-43E1Z | 1190.4 | 984 | 56 | 1092 | 1090 | 1048 | 86 |
| 型號 |
規格 |
重量 | |||||
| Do | di | H | Dr | Di | do | kg | |
| RK6-16N1Z | 518 |
326.4 |
56 |
454 |
412 |
410 |
29 |
| RK6-22N1Z | 648 |
447.0 |
56 |
584 |
542 |
540 |
41 |
| RK6-25N1Z | 748 |
548.6 |
56 |
684 |
642 |
640 |
48 |
| RK6-29N1Z | 848 |
650.2 |
56 |
784 |
742 |
740 |
55 |
| RK6-33N1Z | 948 |
740.0 |
56 |
884 |
842 |
840 |
67 |
| RK6-37N1Z | 1048 |
841.6 |
56 |
984 |
942 |
940 |
75 |
| RK6-43N1Z | 1198 |
994.0 |
56 |
1134 |
1092 |
1090 |
85 |
| 型號 |
規格 |
重量 | ||||||
| Do | di | H | Dr | Di | do | dr | kg | |
| RK6-16P1Z | 518 | 304 | 56 | 454 | 412 | 410 | 368 | 26 |
| RK6-22P1Z | 648 | 434 | 56 | 584 | 542 | 540 | 498 | 34.5 |
| RK6-25P1Z | 748 | 534 | 56 | 684 | 642 | 640 | 598 | 40.4 |
| RK6-29P1Z | 848 | 634 | 56 | 784 | 742 | 740 | 698 | 47.2 |
| RK6-33P1Z | 948 | 734 | 56 | 884 | 842 | 840 | 798 | 53.5 |
| RK6-37P1Z | 1048 | 834 | 56 | 984 | 942 | 940 | 898 | 60 |
| RK6-43P1Z | 1198 | 984 | 56 | 1134 | 1092 | 1090 | 1048 | 69.4 |
